Roller Shutter Filter Cars Filters Paper Coil Filter Auto Roll Filter



What’s Automatic Roll Air Filter?

Automatic Roll Air Filters are advanced air filtration systems designed to maintain clean and efficient airflow in HVAC and industrial applications. These filters use a roll of media that automatically advances when the current section becomes clogged, ensuring uninterrupted performance and reducing maintenance needs. Commonly used in commercial buildings, factories, power plants, and clean rooms, they improve air quality, protect equipment, and enhance energy efficiency. Their self-advancing design makes them ideal for environments requiring reliable and low-maintenance filtration solutions.

Frame material:
Powder coating galvanized steel sheets/Stainless steel
Filter media:
Polyester synthetic fiber,G3, G4 (EN779) efficiency
Power:
as requirements
Customized size:
 Available
Application:
Automatic roll filter is widely used to pre-filter of inductrial ventilation and air
conditioner ventilation system. It’s suitable for high dust capacity environment and the
environments needs frequently change the filter material and constant air flow.
Advantage:
1.Using metal as he overall material,firm and reliable,meet the poorest working environments
2.Intelligent filter replacement system , effective energy conservation , reduce costs
3.Modular design to meet any type of system design and installation requirements
4.Low high-end options for different materials and configurations to meet the needs of
different customers.


 There is a new material boxlocated on the top of the equipment.The initial pressure drop will increase when masses of high contcentration dirty air brought in,and when the initial pressure drip reches final pressure drop,the differential pressure switches opens,the switch will send signal to the control system,motor will work automatically,the dirty filter matrial will be wind onto the lower spool,at the same time clean filter material will take place of the dirty material.


Product features

*  A complete air filter is assembled (includingmedia box, filter media, vertical column,holding bar, etc.)
*  Transmission mechanism
*  Control box
*  Dropout voltage switch
*  Internal connection cable
1: Using metal as he overall material,firm and reliable,meet the poorest working environments
2: Intelligent filter replacement system , effective energy conservation , reduce costs
3: Modular design to meet any type of system design and installation requirements
4: Low high-end options for different materials and configurations to meet the needs of different customers


Product applications

The automatic roll filter is mainly used for the air filtration of the air inlet in the blower room to prevent clogging of the filter system of the blower and prolong its service life.
Primary filtration of industrial ventilation and air conditioning systems.

Auto Roll Filter for Cleaner Room
